Basic Seal Geometry

Seal Master inflatable seals inflate and deflate in three basic directions of operation: the axial (or normal to the mounting plane) direction, the radial-in direction, and the radial-outdirection. Each of these inflation directions has their own set of performance parameters for measurements such as the height of inflation ("stroke" of the seal) and the centerline bend radius that the seal can negotiate.

These performance parameters are further impacted by the cross-section geometry of the seal as well.To obtain an appreciation for the direction of inflation, please view out videos below.

Radial In
Radial Out
Radial In



Radial Out

Axial
